Large Format Single Pass Printer For Honey Board Advertising Pictures
Single Pass Printer Advantage:
High quality digital inkjet printing machine for corrugated carton
Suitable for all kinds of quality orders
4colors,CMYK color mode
Printing speed up to 2.2m/s
Environmental,energy saving, high efficiency and stable operation
Water-based dye ink,Environmental, automatic cleaning system,print on demand
Single Pass Printer Description:
- High speed: the fastest production speed can be 2.2m/s with 600*200dpi, 1.6m/s with 600*300dpi, 0.8m/s with600*600dpi.
- Version costs: traditional printing system need to produce flexor, takes time and money. but WDR200 environmentally printing system do not need it and use inkjet printing technology.
- Labor: the traditional printing system, from the plate to the printing demands worker with high request and number,the process is cumbersome, time-consuming and labor-intensive, reducing production efficiency . WDR200 environmentally printing system use computer plate-making, computer palette and computer save,simple operation, printing on-demand, saving time and labor, high production efficiency.
Single Pass Printer Specifications:
| Article NO. | WDR200-48A/56A/64A/72A/XXX./196A |
| Printhead | Piezoelectric high-procision printhead |
| Ink type | Special waterbase dye ink |
| Color model | Cyan,Magenta,Yellow,Black |
| Medium distance | 2mm-4mm |
| Printing resolution | ≥600*200 dpi |
| Printing efficiency | 600*200dpi, max 2.2m/second;
600*300dpi, max 1.6m/second;
600*600dpi, max 0.8m/second; |
| Material format | Below 1800mm*2400mm under auto feeding ( 2200mm*2400mm can be customized ) |
| Printing format | Below (X)mm*2400mm under auto feeding (X=printhead quantity of single color plus 53.2mm) |
| Drying speed | Dry once print out |
| Working environment | 15ºC-32ºC Indoor,Humidity 20%-70% |
| Ink supply | Automatic continuous ink supply |
| Feeding mode | Automatic feeding |
| Material thickness | 2mm-20mm( between 1.5mm and 20mm will need special Sun feeding system) |
| Thermostat system | Thermostat system with patent |
| Operate system | Professional RIP system,professional printing system,Windows 7 system with 32 bit operating system or above |
| Power supply | About 18 KW power:AC380±10%,50-60HZ |
| Machine size | L*W*H: 6000*4600*1680(mm) |
| Weight | 6500KGS |
Products
Reference Data Sheet of Wonder Printer
| Printing mode | Model | Material | Material size
(mm) | Printing size
(mm) | Solution | Printing speed | Printhead | Production efficiency | Remark |
| Muti -pass | WD250-8A | Y/W kraft liner board | 2500*1350 | 2500*1350 | ≧180*360dpi | max 440㎡/H | EPSON | 100-350(PCS/H) | |
| WD250-16A | Y/W kraft liner board | 2500*1350 | 2500*1350 | ≧180*360dpi | max 780㎡/H | EPSON | 200-700(PCS/H) | |
| WDR250-8A | Y/W kraft liner board | 2500*1350 | 2500*1350 | ≧300*360dpi | max 460㎡/H | RICOH | 120-450(PCS/H) | |
| WDR250-16A | Y/W kraft liner board | 2500*1350 | 2500*1350 | ≧300*360dpi | max 820㎡/H | RICOH | 240-900(PCS/H) |
With drying system can change inks to print on semi coated board |
| WDUV250-12A | Y/W kraft liner board | 2500*1350 | 2500*1350 | ≧360*600dpi | max 230㎡/H | RICOH | 80-250(PCS/H) | |
| WDUV250-24A | Y/W kraft liner board | 2500*1350 | 2500*1350 | ≧360*600dpi | max 460㎡/H | RICOH | 120-450(PCS/H) | |
| Single Pass | WD200-24A | Y/W kraft liner board | 1800*2400 | 592*2400 | 360*180dpi
360*360dpi
360*720dpi | max 0.9 m/s
max 0.6 m/s
max 0.3 m/s | EPSON | 1200-3600(PCS/H) | |
| WD200-32A | Y/W kraft liner board | 1800*2400 | 790*2400 | 360*180dpi
360*360dpi
360*720dpi | max 0.9 m/s
max 0.6 m/s
max 0.3 m/s | EPSON | 1200-3600(PCS/H) | |
| WD200-48A | Y/W kraft liner board | 1800*2400 | 1185*2400 | 360*180dpi
360*360dpi
360*720dpi | max 0.9 m/s
max 0.6 m/s
max 0.3 m/s | EPSON | 1200-3600(PCS/H) | |
| WD200-64A | Y/W kraft liner board | 2200*2400 | 1580*2400 | 360*180dpi
360*360dpi
360*720dpi | max 0.9 m/s
max 0.6 m/s
max 0.3 m/s | EPSON | 1200-3600(PCS/H) | |
| WDR200-48A | Y/W kraft liner board | 1800*2400 | 638*2400 | 600*200dpi
600*300dpi
600*600dpi | max 2.2 m/s
max 1.6 m/s
max 0.8 m/s | RICOH | 3200-12000(PCS/H) |
With drying system can change inks to print on semi coated board |
| WDR200-64A | Y/W kraft liner board | 1800*2400 | 851*2400 | 600*200dpi
600*300dpi
600*600dpi | max 2.2 m/s
max 1.6 m/s
max 0.8 m/s | RICOH | 3200-12000(PCS/H) |
With drying system can change inks to print on semi coated board |
| WDR200-92A | Y/W kraft liner board | 1800*2400 | 1223*2400 | 600*200dpi
600*300dpi
600*600dpi | max 2.2 m/s
max 1.6 m/s
max 0.8 m/s | RICOH | 3200-12000(PCS/H) |
With drying system can change inks to print on semi coated board |
| WDR200-124A | Y/W kraft liner board | 2200*2400 | 1649*2400 | 600*200dpi
600*300dpi
600*600dpi | max 2.2 m/s
max 1.6 m/s
max 0.8 m/s | RICOH | 3200-12000(PCS/H) |
With drying system can change inks to print on semi coated board |
| Single Pass | WDUV200-80A |
All type of cardboard | 1800*2400 | 851*2400 | 600*300dpi
600*600dpi | max 1.5 m/s
max 0.8 m/s | RICOH | 2500-6300(PCS/H) | |
| Muti -pass | WDUV320-16A | Building materials | min 320*320/pcs
max 500*600/pcs | min 320*320/pcs
max 500*600/pcs | ≧360*600dpi | max 1500 pcs/H | RICOH | 1000-1500(PCS/H) | 6 pcs |
| Single Pass | WDUV060-24A | Building materials | 600*600 | 319*600 | ≧300*600dpi | max 1.5 m/s | RICOH | | |
| WDUV060-28A | Building materials | 600*600 | 372*600 | ≧300*600dpi | max 1.5 m/s | RICOH | | |
| WDUV060-32A | Building materials | 600*600 | 425*600 | ≧300*600dpi | max 1.5 m/s | RICOH | | |
| WDUV060-36A | Building materials | 600*600 | 478*600 | ≧300*600dpi | max 1.5 m/s | RICOH | | |
| Remark | 1,Above material size is under auto-feeding situation,the length is no limit if by maual feeding with scaning machine;
2,Auto drying system,auto varnish coating machine and auto slotting machine is optional to marched digital printer;
3,There're special water-based ink,waterproof latex ink and UV curable ink etc.
|
